SUNSKY WD-01ADE WiFi Intelligent Double Path
Watering Device Instructions

Product introduction

Thank you for choosing the WiFi dual-way automatic flower sprayer produced by
our company. This product has a novel appearance, suitable for home, office
and other scenarios; Selected high quality ABS+PP raw materials, anti-brittle
cracking oxidation performance is good. The product is developed based on the
Internet of Things platform. It is connected to WiFi and can be controlled
remotely after setting through mobile APP. You can set the watering time and
frequency in the APP according to your needs. The chip has built-in clock
function, and the flower sprayer will also work on time according to your
setting when offline. This product is equipped with domestic famous brand
miniature diaphragm pump, with high efficiency, low noise, small vibration,
high suction, high head, long life and many other advantages. 4 AA batteries
and adapter dual-mode uninterrupted power supply, high quality WIFI module
with SMT process control module, safe and reliable, let you easily, carefree.

Function introduction

When you click Set / MA, pump a will run manually; when you click Set / MB,
pump B will run manually; long press the key for 5 seconds to switch the
matching mode.

Product parameters

Rated voltage：5 V
Rated current：720 mA
Power：3.6 W
Connection calibre：∅ 4.8 mm
Maximum pressure:≥30psi(200kpa)
Water flow：0.3-0.8 LPM
Noise range：≤65 db(30cm）
Size ：838395（LWH)
net weight： 240g
Body material: >ABS<
Water pipe：4/6 ,4/7
Battery model： 4-AA 1.5v
Adapter: DC 5V 2A DC002 3.5/1.3
Ambient temperature：0℃-50 ℃
Lift ：≥2.5 m
Suction：≥2m
Wifi: 2.4GHz

Connection method

Operation process

Download app ▶ registration & login ▶ connection device ▶ setting parameters

Download app

Search “ewelink” by mobile phone, download and install the app.

Registration & login

Users in the mainland of China can register with their mobile phone numbers,
while users in other regions can register and log in by email. If you have
already registered an e-micro account, you can enter your account to log in.

Connection device

Power on the watering device and keep it in the same WiFi signal with the
mobile phone, and ensure that the WiFi is 2.4GHz. At this time, the blue
signal indicator lights up, and different flashing modes represent different
states, as follows:

2short and 1 long: pairing mode slow flash: offline / unconnected continuous
flash: compatible pairing mode normally on: Networking

When the unpaired device is powered on, it is in pairing mode by default (2
short and 1 long). Long press any setting button for 5 seconds to switch to
compatible pairing mode (continuous flash); when offline (slow flash), long
press any setting button for 5 seconds to enter pairing mode (2 short and 1
long).

Please note that

1. The mobile phone and flower watering device should be close to the router as far as possible to obtain stronger WiFi signal; WiFi must be 2.4GHz.
2. During pairing, please make sure that the device is in pairing mode (signal light status is 2 short and 1 long). If it is not in pairing mode, you can press any key for 5 seconds to switch modes.
3. In case of pairing failure, please check the software permission settings to ensure that the app has WiFi and location access rights.
4. Pairing always fails. Please try compatible pairing mode.

compatible pairing mode

When pairing mode fails to connect normally, you can select compatibility mode
to connect. When connecting, please adjust the matching mode of flower
watering device to “compatible matching mode”, and the signal indicator light
is continuous flash. At this time, according to the hot spot name and password
prompted by the mobile phone, select to connect to the hot spot. In the pop-up
dialog box, allow ewelink to join WLAN.

setting parameters

After adding the device, click to enter the device to set the working time and
frequency of the flower watering device according to your needs.

Watering working time setting: enter the equipment interface — click option
setting (three points in the upper right corner) — inching setting. Turn on
the inching state of channel 1 and channel 2, and set the watering time you
need (channel 1 is pump a, channel 2 is pump B). After setting, please click
the top right corner to save. Under the manual or automatic state, the water
pump will run according to the inching time you set, and stop after reaching
the set time.

Timing scheme setting

click the timing icon — add a new timing scheme — select time, date and
channel (action mode is open) — please click save after setting.

Please note that

1. Channel 1 corresponds to pump a; channel 2 corresponds to pump B. the starting time of the two pumps is set separately, and the user can set multiple groups of watering schemes.
2. After setting, whether the device is online or offline, the built-in chip will execute the setting procedure on time according to the setting.

matters needing attention

1. Large capacity and small calibre containers (such as pure water bucket) should be selected as far as possible to meet the capacity demand and reduce water evaporation;
2. The position of the water container is relatively lower than the flowerpot to prevent the water in the bucket from directly flowing into the flowerpot without starting up in the sealed pipeline.
3. When it is difficult to plug in and out the pipeline, hot water can be used to soften it before plugging in and out.
4. Correctly use the inlet pipe filter, and do not use the sewage with large particle impurities as the water source to prevent blocking the water pipe or pump.
5. Before setting the watering time, test the water flow and time manually.
6. The host has built-in circuit control board. Please do not place it in the open air. Rain, soaking and other harsh environment will cause fatal damage to the host.
7. When not in use for a long time, pull out the adapter, take out the battery, and properly place the host in a dry environment.
8. Under the condition of only using battery power supply, the endurance depends on the working frequency, working intensity, battery performance and other comprehensive conditions. When replacing batteries, 4 batteries need to be replaced at the same time.
9. The automatic watering device is only used for intermittent watering, and can not be used as a pump to continuously transport fluid medium for a long time, otherwise it will seriously reduce the service life of the main engine diaphragm pump.

FCC WARNING
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation. Any changes or
modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment. NOTE: This equipment
has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the
following measures:
— Reorient or relocate the receiving antenna.
— Increase the separation between the equipment and receiver.
— Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
— Consult the dealer or an experienced radio/TV technician for help. To
maintain compliance with FCC’s RF Exposure guidelines, This equipment should
be installed and operated with minimum 20cm distance between the radiator and
your body: Use only the supplied antenna.
